Specifications in detail
Overview
Number of Microphone Preamps2
Phantom PowerYes
Instrument Inputs2
Line Inputs2
Air ModeYes
Auto GainYes
Clip SafeYes
Line Outputs2
Headphone Outputs1
LoopbackYes
ConnectivityUSB Type-C
ProtocolUSB 2.0
Form FactorDesktop
Simultaneous I/O4 x 2 (including Loopback inputs)
A/D Resolution24-bit/192 kHz
Bus PoweredYes (900mA)
Dimensions
Height47.5mm
Width180mm
Depth117mm
Weight0.595kg
Supported sample rates
44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz
Microphone inputs
Frequency Response20-20kHz ± 0.06dB
Dynamic Range116dB (A-Weighted)
THD+N-100dB @ 8dB gain
Noise EIN-127dBu (A-Weighted)
Maximum Input Level16dBu
Gain Range69dB
Impedance3kΩ
Line inputs
Frequency Response20-20kHz ± 0.05dB
Dynamic Range115.5dB (A-Weighted)
THD+N-100dB @ 8dB gain
Maximum Input Level22dBu
Gain Range69dB
Impedance60kΩ
Instrument inputs
Frequency Response20-20kHz ± 0.15dB
Dynamic Range113dB (A-Weighted)
THD+N-80dB @ minimum gain
Maximum Input Level12dBu
Gain Range62dB
Impedance1MΩ
Line outputs (Balanced)
Frequency Response20-20kHz ± 0.02dB
Dynamic Range120dB
THD+N-109dB
Maximum Output Level16dBu
Impedance100Ω
Headphone outputs
Frequency Response20-20kHz ± 0.1dB @ 33Ω / 300Ω
Dynamic Range112dB @ 33Ω
115dB @ 300Ω
THD+N-99dB @ 33Ω
-108dB @ 300Ω
Maximum Output Level2.5dBu into 33Ω
10dBu into 300Ω
Maximum Output Power32mW into 33Ω
22mW into 300Ω
Impedance50Ω
Analogue to Digital Converter
THD+N-110dB
Dynamic Range120dB
Digital to Analogue Converter
THD+N-115dB
Dynamic Range130dB (A-Weighted)
Power
USB900mA
External (Optional)4.5W
